Features
FMC series full servo combined multifunctional window patching machine, this model has both high-speed window patching and V-cutting and line-pres- sing window pasting. The machine is equipped with 10 sets of servo motors.The main feature of the machine is full intelligent adjustment of various para- meters. Each action of the whole machine is driven by an independent servo motor. which can digitally adjust the front and rear positions of glue and ad- hesive film on the man-machine interface without stopping, The placement accuracy can be kept unchanged during the acceleration of the machine, The maximum speed of single channel operation can reach 25000 sheets 1 hour, and the patch accuracy can be controlled within 1mm. The maximum speed of V-cutting and line- pressing window patching can reach 8000 sheets/hour, and the pasting accuracy can be controlled within the range of士0.5mm.lt is equipped with intelligent vacuum adsorption system. The suction box adopts sectional opening and closing function to ensure the stability of produc- tion products in an all-round way. The machine has the characteristics of stability, high efficiency, quiet and inteligent operation.
Parameters

Model	FMC-750VS	FMC-920VS	FMC-1100VS(Optional double channel model)
Paper size	W730mm×L650mm - W150mm×L150mm	W900mm×L720mm - W150mm×L150mm	W1100mm×L720mm - W150mm×L150mm
Film size	W400mm×L350mm - W30mm×L40mm	W500mm×L450mm - W30mm×L50mm	W650mm×L450mm - W30mm×L50mm
Paper thickness	Cardboard:200-1000g/㎡ Corrugated board:1-4mm	Cardboard:200-1000g/㎡ Corrugated board:1-5mm	Cardboard:200-1000g/㎡ Corrugated board:1-5mm
Film thickness	PET:0.03~0.2mm   PVC:0.03~0.25mm	PET:0.03~0.25mm   PVC:0.03~0.3mm	PET:0.03~0.25mm   PVC:0.03~0.3mm
Positioning accur	Top/bottom ± 1 mm(V-cutting ±0.5mm)	Top/bottom ± 1 mm(V-cutting ±0.5mm)	Top/bottom ± 1 mm(V-cutting ±0.5mm)
Mechanical speed	3000-25000 sheet/hour(V-cutting Max 8000Pcs/H)	3000-25000 sheet/hour(V-cutting Max 8000Pcs/H)	3000-25000 sheet/hour(V-cutting Max 8000Pcs/H)
Power voltage	380 V/50HZ（three phase)	380 V/50HZ（three phase)	380 V/50HZ（three phase)
Power required	24KW	26KW	28.5 KW
Weight machine	3150KG	3550 KG	3850 KG
Dimension (L x W x H)	L8800mm×W1550mm×H1750mm	L8800mm×W1630mm×H1750mm	L8800mm×W1850mm×H1750mm
